To use the AT90S2313 with AVR910 code, insert these to lines immediately after the reset label. Read the application note carefully and reproduce the design as faithfully as you can and you shouldn’t have any trouble.Note: you can use an AT90S2313 instead of an AT90S1200 if you add two lines to initialize the stack pointer, since the AT90S2313 is a superset of the AT90S1200, the difference being that the ‘1200 has a hardware stack and thus does not require pointer initialization. Build your fist one as faithfully as you can according to the application note -this application note is several years old and Atmel has had adequate opportunity to receive feedback on it an make corrections, while my changes have only been applied to one programmer.

Program at90s2313 with arduino uno board software#

The LED on the reset line show right away whether the hardware is really programming the chip as the software says. Sometimes the AVR Programming application from Atmel gets out of sync with the programmer (this does not happen with MacAVRpa ).

Program at90s2313 with arduino uno board series#

In one unit I used 39k resistors for R105, R102, and R104 to save power and they worked fine (I used a 2N2907 for Q100 and a 2N2222 for Q101).The programmer in the image on this page differs from that described in the Atmel application note in that there is an LED and series resistor connected across the power supply to indicate the presence of voltage, and an LED with series resistor connected from the +5V to the ATS90S1200 pin 16 (reset output) to indicate programmer activity. Though I have not surveyed all of the AVR devices, R103 and R106 are superfluous at least for the AT90S1200 and AT90S2313 and may be omitted. Take note that R101 does not do anything important and can be omitted. It is an amazing demonstration of what can be done in 1K or ROM and only a 3 level deep stack. Assembler and programming software.Windows: AVR Prog application that comes with AVR StudioAVR Studio is a complete development package and includes a fairly good simulator.A few notes on variations and resourcesThe design is clever and works very well.

I am trying this one cautiously and so far I am happy with the way it works while programming that AT90S2313.HEX FILES for AT90S1200For use with AVR Studio’s programming tool (Windows):,For use with MacAVRpa for the Mac:HEX FILES for AT90S2313 For use with AVR Studio’s programming tool (Windows):or use with MacAVRpa for the Mac:3. Note the cautions at the top of the file: MOSI and MISO lines have been swapped and need to be swapped back to work with the original AVR910 hardware (go to the.equ statements and make MOSI= 6 and MISO = 5).

Program at90s2313 with arduino uno board code#

Check Atmel’s site for the latest version atASSEMBLY CODE for AT90S2313:For a wider selection of supported chips (including more ATMEGA and ATTiny chips, here is a realtively un-tested version for the AT90S2313 written by a person named J. See below for info on a preprogrammed chip.ASSEMBLLY CODE for AT90S1200. AVR910 application note.check Atmel’s site for the latest version2.Assembly code for the AT90S1200 micro controller, including the file, 1200def.inc, that comes with both of the assemblers mentioned here. In addition to the electronic components, you need these things to build and use the programmer based on the AVR910 application note.1. The programmer works seamlessly with the programmer application that comes with the AVR Studio package and also seamlessly with MacAVRpa, an assembler/programmer application for the Macintosh.Though several web sites mentioned the programmer, even after finding the application note, I still had questions, so I decided to put the bulk of the information here for anyone who might be starting down the same road. The 6 pin cable as well as the rest of the system is clearly explained in the AVR910 application note. The target also supplies power to the programmer.

The target controller needs to have its own clock and power supply. It connects to a target controller via a 6 pin cable.

Program at90s2313 with arduino uno board serial#

These programmers are compatible with RS-232 ports, cost well under US$10 to build, and program AVR chips in the serial mode (and thus is not able to access programming options only available in parallel mode -read those data sheets!). Share this.Atmel described a simple programmer based on the AT90S1200 (NOT the AT90S1200A) controller in their application note, AVR910 (a modification to use the AT90S2313 is also given below).The circuit is so small and simple, I was able to put two of them together without using a printed circuit board, taking only about an hour to assemble each one.
